Model: Steel Strip for Measuring Tape Spring & Blade


Model: Steel Strip for Measuring Tape Spring & Blade
Product Name:
Packing:
Others:

Description:

Our steel strip is used for producing steel blade and spring for measuring tape, It's cold carbon steel strip 50# and 60# whose width is 154mm and thickness 0.090-0.125mm, thickness tolerance is +/-0.005mm. Below is a mainly chemical analysis.

Item Size Chemical Analysis
No. (mm) C Si Mn S P
C60 0.100x154 0.58-0.62 0.19-0.22 0.53-0.60 0.005-0.016 0.009-0.020
  0.118x154 0.58-0.62 0.19-0.22 0.53-0.60 0.005-0.016 0.009-0.020
  0.125x154 0.58-0.62 0.19-0.22 0.53-0.60 0.005-0.016 0.009-0.020
